PRODUCTION ENHANCEMENT SYSTEMS

LOW PRESSURE - CONDENSATE RECOVERY SYSTEM (LP-CRS)

About the System

The LP-CRS unit is designed to enhance condensate recovery from associated gases (typical recovery ranging from 50 to 100 bbls per MMSCFD of gas). The main objective of the LP-CRS is to recover condensates (C4+ components) from the associated gases which will be otherwise flared or vented. The system uses the Evaporative Dew-Point Control Unit (EDPCU) which employs the Joule-Thompson cooling effect coupled with evaporative cooling to enhance condensate recovery.

WhatsApp Image 2017-10-26 at 10.44
WhatsApp Image 2017-10-26 at 10.44

WhatsApp Image 2017-10-26 at 10.44
WhatsApp Image 2017-10-26 at 10.44

WhatsApp Image 2017-11-01 at 6.09.21 PM.
WhatsApp Image 2017-11-01 at 6.09.21 PM.

WhatsApp Image 2017-10-26 at 10.44
WhatsApp Image 2017-10-26 at 10.44

1/4
Benefits

Self-contained, compact and light weight.


Reduce Greenhouse Gas (CO2) emissions by 20% to 30%.


None or minimal rotating equipment resulting to high availability, easy operation and low maintenance.


LP-CRS comes together with hydrate inhibition and anti-freeze agent (MEG) which is recovered in the process.


Improved crude quality and reduce wax deposition for fields facing wax issues

Applications

LP-CRS unit can be applied on the flare/vent system.


The system is suitable for both onshore and offshore installations particularly for facilities where it is not economically viable to install a gas plant with NGL or LPG extraction facilities.


The Joule-Thompson (JT) device for LP-CRS can either be a JT valve system or turbo-expander system, LP-CRS (T).

TRACK RECORDS

Sep-iSYS LPPU for West
Lutong Drilling Platform -
B, Miri, for PETRONAS
Carigali - SKA
